SICK microScan3 Core I/O User Manual

190 mm
150 mm
S
L
Figure 36: Recommended fitting height
110 mm
150 mm
S
L
Figure 37: Recommended fitting height for inverted mounting
5.4 Integrating the equipment into the electrical control
This chapter contains important information about integration in the electrical control.
Inf
ormation about the individual steps for electrical installation of the device: see
"Electrical installation", page 69.
Information about pin assignment: see "Pin assignment", page 71.
