SICK microScan3 Core I/O User Manual

LS-MS3-CO-IO-5M
Devices with a max. protec‐
t
ive field range of 5.5 m
≤ 40 m
Distance measurement range
Devices with a max. protec‐
tive field range of 5.5 m
≤ 40 m
Fields ≤ 8
Simultaneously monitored
f
ields
≤ 4
Field sets ≤ 8
Monitoring cases ≤ 2
Scanning angle 275° (–47.5° to 227.5°)
Protective field resolution 30 mm, 40 mm, 50 mm, 70 mm, 150 mm, 200 mm
Angular resolution
Devices with a max. protective field range of 5.5 m
Scan cycle time 30 ms 0.51°
Scan cycle time 40 ms 0.39°
Response time
Devices with a max. protec‐
t
ive field range of 5.5 m
≥ 70 ms, details: see "Response times", page 147
Scan cycle time
Devices with a max. protec‐
tive field range of 5.5 m
30 ms or 40 ms (configurable)
Generally necessary protective field supplement (TZ = tolerance range of the safety laser
sc
anner)
Devices with a max. protec‐
tive field range of 5.5 m
65 mm
Additional supplement
Z
R
f
or reflection-based mea‐
surement errors
350 mm
Deviation from ideal flatness
of sc
an field at 5.5 m
≤ ± 100 mm
Distance of mirror rotational
axis (zero point of x and y
axis) to rear side of device
56 mm
Distance between center
point of scan plane and top
edge of the housing
40 mm
Multiple sampling 2 … 16
Safety-related parameters
T
able 27: Safety-related parameters
LS-MS3-CO-IO-5M
Type Type 3 (IEC 61496)
Safety integrity level SIL 2 (IEC 61508)
SIL claim limit SILCL 2 (IEC 62061)
Category Category 3 (ISO 13849-1)
Performance level PL d (ISO 13849-1)
TECHNICAL DATA 14
