SICK microScan3 Core I/O User Manual

LS-MS3-CO-IO-5M
Sampling time 4 ms
Response time at EDM after
s
witching on OSSDs (when
used as EDM input)
300 ms
Actuating duration of control
switch for reset (when used
as reset input)
60 ms to 30 s
Actuating duration of switch
for sleep mode (when used
as sleep mode input)
≥ 120 ms
1)
The power supply unit must be able to jumper a brief power failure of 20 ms as specified in
IE
C 60204-1. Suitable power supply units are available as accessories from SICK.
2)
The voltage level must not fall below the specified minimum voltage.
3)
In the event of a fault (interruption of the 0 V cable), the specified leak current at most flows in the OSSD
cable. The downstream control element must detect this state as the OFF state.
Mechanical data
T
able 30: Mechanical data
LS-MS3-CO-IO-5M
Dimensions (W × H × D) 112 mm × 135.1 mm × 111.1 mm
Weight (including system
plu
g)
1.15 kg
Housing material Aluminum
Housing color RAL 9005 (black) and RAL 1021 (colza yellow)
Optics cover material Polycarbonate
Optics cover surface Outside with scratch-resistant coating
Ambient data
T
able 31: Ambient data
LS-MS3-CO-IO-5M
Enclosure rating
1)
IP65 (IEC 60529)
Ambient light immunity ≤ 3,000 lx (IEC 61496-3)
Ambient operating tempera‐
t
ure
–10 °C … 50 °C
Storage temperature –25 °C … 70 °C
Air humidity ≤ 95%, non-condensing
2)
Height above sea level during
oper
ation
≤ 2300 m
Vibration resistance
3)
Standards
•
IE
C 60068-2-6
•
IEC 61496-1, Clause 4.3.3.1 and 5.4.4.1
•
IEC 61496-3, Clause 5.4.4.1
Frequency range 10 Hz … 150 Hz
Amplitude 0.35 mm (10 Hz to 60 Hz), 5 g (60 Hz to 150 Hz)
Shock resistance
3)
Standards
•
IE
C 60068-2-27
•
IEC 61496-3, Clause 5.4.4.4.2 and Clause 5.4.4.4.3
Single shock 15 g, 11 ms
14 TECHNICAL DATA
146
O P E R A T I N G I N S T R U C T I O N S | microScan3 Core I/O 8025870/2020-09-04 | SICK
Subject to change without notice
