SICK microScan3 Core I/O

Prerequisites
•
Exis
ting connection between Safety Designer and device
•
Configuration in the project and configuration in the device are synchronized
Approach
1. Import configuration from the device.
2. Take an image.
12.4.2 Event history
Overview
Figure 84: Event history
1
Data source
2
Available views
3
Navigation
The safety laser scanner stores data on important events. The event history displays
inf
ormation about the most recently stored events.
Event memory in the safety laser scanner
T
he safety laser scanner stores data on the following events:
•
Safety output switches to the OFF state
•
The protective field, the reference contour field or the contour identification field is
interrupted
12 T
ROUBLESHOOTING
138
