SICK microScan3 Core I/O

LS-MS3-CO-IO-5M
Continuous shock 10 g, 16 ms
EMC In accordance with IEC 61496-1, IEC 61000-6-2, and
IE
C 61000-6-4
1)
The specified enclosure rating is only valid if the safety laser scanner is closed, the system plug is
mount
ed and all of the safety laser scanner’s M12 system plugs are closed using a male cable connector
or using a protective cap.
2)
IEC 61496-1, no. 4.3.1 and no. 5.4.2, IEC 61496-3, no. 4.3.1 and no. 5.4.2. Condensation has an
influence on normal operation.
3)
For direct mounting.
Miscellaneous data
T
able 32: Miscellaneous data
LS-MS3-CO-IO-5M
Wavelength 845 nm
Detectable reflectance factor 1.8% to several 1,000%
Maximum uniform contami‐
na
tion of the optics cover
without reducing the detec‐
tion capability
1)
30 %
Area where detection capabil‐
it
y is restricted
≤ 50 mm
2)
Light spot diameter
At front screen 18 mm
At 4.0 m distance 12 mm
At 5.5 m distance 20 mm
At 9.0 m distance 30 mm
Divergence of collimated
be
am
0.17°
Receiving angle 0.75°
Pulse duration Typ. 4 ns
Average output power 9.2 mW
Laser class 1M
1)
In the event of heavy contamination, the safety laser scanner displays a contamination error and
s
witches all safety outputs to the OFF state.
2)
In close proximity (50 mm-wide area in front of the optics cover), the detection capability of the safety
laser scanner may be restricted. If required, this area must be secured using an undercut or frame, for
example.
14.4 Response times
The protective device’s response time is the maximum time between the occurrence of
t
he event leading to the sensor’s response and supply of the switch-off signal to the
protective device’s interface (for example OFF state of the OSSD pair).
