SICK microScan3 Core I/O

8.11.3 Input conditions
For each monitoring case, choose the input conditions for which the monitoring case
w
ill be activated.
b
Activate the combination of inputs for each monitoring case.
✓
The relevant monitoring case is activated for exactly this combination.
✓
Combinations which are invalid or already assigned are marked.
8.11.4 Cut-off paths
You can create cut-off paths and define the outputs switched by the cut-off paths.
(Ex
ample: the protective fields switch the OSSD pair, the warning fields switch a univer‐
sal output.)
You need a cut-off path for every field in a field set. If the field sets have different sizes,
use the field set with the most fields as a guide.
Creating cut-off path and entering a name
1.
Create a cut-off path for every field in the largest field set.
2. Enter a descriptive name for each cut-off path.
Assigning an OSSD pair
b
Place a check in the box for the OSSD pair.
✓
The OSSD pair is assigned to the cut-off path.
Assigning unsafe outputs
b
Place a check in the box for the universal output(s).
✓
The universal output is assigned to the cut-off path.
8.11.5 Assigning field sets
Assigning a field set to a monitoring case
T
he field sets that have been created are shown in the area Field sets on the right.
1. Create cut-off paths, see "Cut-off paths", page 107.
2. Drag the field set onto the monitoring case.
✓
The fields in a field set are arranged as they were drawn in the field editor (for
example protective field, warning field, warning field).
Deleting the assignment of a field set from the monitoring case
b
Drag the field set from the monitoring case table onto the trash-can icon.
✓
The field set is removed from the relevant monitoring case.
Defined cut-off behavior
DANGER
H
azard due to lack of effectiveness of the protective device
Persons and parts of the body to be protected may not be recognized in case of
non-observance.
The function Always ON has the same effect as a field which is always clear. In a
monitoring case with the Always ON function, the cut-off path containing this function is
permanently in the ON state.
b
Dr
ag the Always OFF function onto the cut-off path.
✓
The field is viewed as being permanently interrupted.
If the monitoring case becomes active, the cut-off path is always in the OFF state.
CONFIGURATION 8
8025870/2020-09-04 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 Core I/O
107
