The protective field range is shown to you, see "P
arameters for the safety laser scan‐
ner", page 87.
Multiple sampling
DANGER
H
azard due to lack of effectiveness of the protective device
Persons or parts of the body to be protected may not be recognized or not recognized in
time in case of non-observance.
A higher multiple sampling increases the response time.
b
Make a note of the safety laser scanner’s new response time in Safety Designer.
b
Adjust the minimum distance from the hazardous point to the new response time.
Multiple sampling indicates how often an object has to be scanned before the safety
la
ser scanner reacts. A higher multiple sampling reduces the possibility that insects,
weld sparks or other particles cause the machine to be shut down. You will increase the
machine’s availability.
A multiple sampling of 2 is the minimum setting.
b
Increase the multiple sampling up to 16.
✓
An object must be this many times.
Table 9: Recommended multiple sampling
Application Recommended multiple sampling
Stationary application: such as horizontal haz‐
ar
dous area protection or vertical hazardous
point protection under clean ambient condi‐
tions
2×
Stationary application: such as vertical access
pr
otection
Only 2-time multiple sampling may be used for
vertical access protection.
2×
Mobile application 4×
Stationary application: such as horizontal haz‐
ar
dous area protection under dusty ambient
conditions
8×
8.7.2 Parameters for the safety laser scanner
Overview
Configure the parameters for the safety laser scanner here.
Scan cycle time
You can configure the scan cycle time. The safety laser scanner’s scan cycle time
influences the response time and the protective field range.
•
40 ms: Full protective field range, increased availability in dusty conditions, for
example
•
30 ms: Smaller protective field range with shorter response time
b
Select scan cycle time.
✓
The resulting response time and the range of the fields are shown.
CONFIGURATION 8
8025870/2020-09-04 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 Core I/O
87
Subject to change without notice
