SICK microScan3 Core I/O User Manual

LS-MS3-CO-IO-5M
PFH
D
(me
an probability of a
dangerous failure per hour)
8 × 10
–8
T
M
(mis
sion time) 20 years (ISO 13849-1)
Safe status when a fault
oc
curs
At least one OSSD is in the OFF state.
Interfaces
T
able 28: Interfaces
LS-MS3-CO-IO-5M
OSSD pairs 1
Automatic restart of OSSDs
af
ter
2 s to 60 s (configurable)
Voltage supply
Connection type Male connector, M12, 8-pin, A-coding (collective male connec‐
tor for voltage supply and inputs and outputs)
Length of cable (power supply unit tolerance ± 5%)
Length of cable with wire
cr
oss-section 0.25 mm
²
≤ 35 m
Local inputs and outputs
Connection type Male connector, M12, 8-pin, A-coding (collective male connec‐
t
or for voltage supply and inputs and outputs)
Length of cable with wire
cross-section 0.25 mm²
≤ 35 m
Configuration and diagnostic interface
Type of interface USB 2.0
Connection type USB 2.0 mini-B (female connector)
Transmission rate ≤ 12 Mbit/s
Length of cable ≤ 5 m
Electrical data
T
able 29: Electrical data
LS-MS3-CO-IO-5M
Operating data
Protection class III (IEC 61140)
Supply voltage U
V
24 V DC (16.8 V to 30 V DC) (SELV/PELV)
1)
Residual ripple ± 5 %
2)
Start-up current at 24 V ≤ 3 A
Current consumption at 24 V
No output load Typ. 0.3 A
With maximum output load Typ. 1.4 A
In sleep mode, no output
load
Typ. 0.27 A
Power consumption
No output load Typ. 7 W
With maximum output load Typ. 34 W
14 TECHNICAL DATA
144
O P E R A T I N G I N S T R U C T I O N S | microScan3 Core I/O 8025870/2020-09-04 | SICK
Subject to change without notice
