DANGER
H
azard due to lack of effectiveness of the protective device
In the case of non-compliance, it is possible that the dangerous state of the machine
may not be stopped or not stopped in a timely manner.
In addition to the protective device’s response time, further signal transmission and
processing also influence the time up until the end of the dangerous state. This
includes a control’s processing time and the response times of downstream contactors,
for example.
b
Take the time for further signal transmission and processing into account.
Response time
T
he safety laser scanner’s response time depends on the following parameters:
•
Scan cycle time
•
Set interference protection
•
Set multiple sampling
You can calculate the response time using the following formula:
t
R
= (t
S
+ t
I
) × n + t
O
The following rules apply:
•
t
R
= response time
•
t
S
= scan cycle time
°
Setting “30 ms”: t
S
= 30 ms
°
Setting “40 ms”: t
S
= 40 ms
•
t
I
= time for interference protection
°
Mode 1 (default): t
I
= 0 ms
°
Mode 2: t
I
= 1 ms
°
Mode 3: t
I
= 2 ms
°
Mode 4: t
I
= 3 ms
•
n = set multiple sampling
Preset to n = 2.
Multiple sampling can be changed for the safety laser scanner or for each individ‐
ual f
ield (2 ≤ n ≤ 16).
•
t
O
= t
ime for processing and output
Dependent on output used:
°
O
SSD pair 1: t
O
= 10 ms
Table 33: Response time of an individual safety laser scanner
Scan cycle time (t
S
) Interference protec‐
t
ion (t
I
)
Output (t
O
) t
R
= response time for
multiple sampling n
30 ms Mode 1 0 ms OSSD pair 1 n × 30 ms + 10 ms
Mode 2 1 ms OSSD pair 1 n × 31 ms + 10 ms
Mode 3 2 ms OSSD pair 1 n × 32 ms + 10 ms
Mode 4 3 ms OSSD pair 1 n × 33 ms + 10 ms
40 ms Mode 1 0 ms OSSD pair 1 n × 40 ms + 10 ms
Mode 2 1 ms OSSD pair 1 n × 41 ms + 10 ms
Mode 3 2 ms OSSD pair 1 n × 42 ms + 10 ms
Mode 4 3 ms OSSD pair 1 n × 43 ms + 10 ms
