SICK TR4 User Manual

Chapter 10 Operating Instructions
TR4
100 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8014467/YTD7/2016-03-30
Subject to change without notice
Ordering information
en
10.4 Plug connectors and cables
Part Part number
(type code)
Connecting cable 4-core
with M12 female connector, 4-pin, straight/stripped
2 m 6025900
(DOL-1204-G02MC)
5 m 6025901
(DOL-1204-G05MC)
10 m 6025902
(DOL-1204-G10MC)
Connecting cable 8-core
with M12 female connector, 8-pin, straight/stripped
2 m 6020633
(DOL-1208-G02MA)
5 m 6020993
(DOL-1208-G05MA)
10 m 6022152
(DOL-1208-G10MA)
Connecting cable 5-core
with M12 female connector, 5-pin, straight/stripped
2 m 6025906
(DOL-1205-G02MC)
5 m 6025907
(DOL-1205-G05MC)
10 m 6025908
(DOL-1205-G10MC)
Connection cable 4-core
with M12 female connector, 4-pin, straight/M12 male connector,
4-pin, straight
2 m 6022567
(DSL-1204-G02M)
5 m 6022569
(DSL-1204-G05M)
10 m 6034406
(DSL-1204-G10M)
Tab. 12: Part numbers
plug connectors and
cables

SICK TR4 Specifications

General

Number of Safe Outputs	2
Output Type	PNP
Protection Rating	IP67
Type	Safety Switch
Housing Material	Plastic
Supply Voltage	24V DC
Connection Type	Cable
Operating Voltage	24 V DC
Operating Temperature	-25 °C ... +70 °C
Actuator Type	Separate actuator (TR4 Direct, TR4 Standard, TR4 Extended)
