Chapter 9 Operating Instructions
TR4
96 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8014467/YTD7/2016-03-30
Subject to change without notice
Technical specifications
en
9.3 Dimensional drawings
9.3.1 Dimensional drawing TR4 Direct sensor
Fig. 16: Dimensional
drawing TR4 Direct
sensor (mm)
24.99 20.65
4.57
88.14
M12
×
1
9.7
9.96
4.57
⊕
5.08
4.57
57.96
62.53
77.98
82.55
13.41
Plug version
10.67
18.54
