SICK TR4 User Manual

Chapter 10 Operating Instructions
TR4
98 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8014467/YTD7/2016-03-30
Subject to change without notice
Ordering information
en
10 Ordering information
10.1 Safety switches
10.1.1 TR4-SDxxxx Standard transponder safety switches
Items supplied: sensor, actuator, operating instructions
Part number
(type code)
Connection type of the sensor
Multicoded Unique Coded
Cable 3 m, PVC 6044636
(TR4-SDM03P)
6044639
(TR4-SDU03P)
Cable 10 m, PVC 6044637
(TR4-SDM10P)
6044640
(TR4-SDU10P)
Cable with M12 plug, 8-pin 6044638
(TR4-SDM01C)
6044641
(TR4-SDU01C)
Cable with M12 plug, 5-pin 6034573
(TR4-SDM02C)
6034577
(TR4-SDU02C)
10.1.2 TR4-SExxxx transponder safety switches with
boundary area indication
Items supplied: sensor, actuator, operating instructions
Part number
(type code)
Connection type of the sensor
Multicoded Unique Coded
Cable 3 m, PVC 6044642
(TR4-SEM03P)
6044645
(TR4-SEU03P)
Cable 10 m, PVC 6044643
(TR4-SEM10P)
6044646
(TR4-SEU10P)
Cable with M12 plug, 8-pin 6044644
(TR4-SEM01C)
6044647
(TR4-SEU01C)
Cable with M12 plug, 5-pin 6034578
(TR4-SEM02C)
6034583
(TR4-SEU02C)
Tab. 7: Part numbers
TR4-SDxxxx safety
switches
Tab. 8: Part numbers
TR4-SExxxx safety
switches

SICK TR4 Specifications

General

Number of Safe Outputs	2
Output Type	PNP
Protection Rating	IP67
Type	Safety Switch
Housing Material	Plastic
Supply Voltage	24V DC
Connection Type	Cable
Operating Voltage	24 V DC
Operating Temperature	-25 °C ... +70 °C
Actuator Type	Separate actuator (TR4 Direct, TR4 Standard, TR4 Extended)
