SICK TR4 User Manual

Operating Instructions Chapter 10
TR4
8014467/YTD7/2016-03-30 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 101
Subject to change without notice
Ordering information
en
Part Part number
(type code)
Connection cable 8-core
with M12 female connector, 8-pin, straight/M12 male connector,
8-pin, straight
2 m 6030121
(DSL-1208-G02MAC)
5 m 6032325
(DSL-1208-G05MAC)
10 m 6034901
(DSL-1208-G10MAC)
10.5 Recommended safe control solutions
The following safe control solutions in the SICK “sens:Control” product
range are recommended for usage with the TR4 safety switch.
Part Part number
(type code)
Safety relays
UE48 safety relay 6024916
(UE48-2OS3D2)
Flexi Classic safety controller
Main module 6026136
(UE410-MU3T5)
Input/output extension module 6032470
(UE410-XU3T5)
Input expansion unit 6026139
(UE410-8DI3)
Tab. 13: Part numbers
safe control solutions

SICK TR4 Specifications

General

Number of Safe Outputs	2
Output Type	PNP
Protection Rating	IP67
Type	Safety Switch
Housing Material	Plastic
Supply Voltage	24V DC
Connection Type	Cable
Operating Voltage	24 V DC
Operating Temperature	-25 °C ... +70 °C
Actuator Type	Separate actuator (TR4 Direct, TR4 Standard, TR4 Extended)
