SICK TR4 User Manual

Operating Instructions Chapter 10
TR4
8014467/YTD7/2016-03-30 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 99
Subject to change without notice
Ordering information
en
10.1.3 TR4-SFxxxx transponder safety switches with
boundary area indication and with magnetic
retaining force
Items supplied: sensor, actuator, operating instructions
Part number
(type code)
Connection type of the sensor
Multicoded Unique Coded
Cable 3 m, PVC 6044648
(TR4-SFM03P)
6044651
(TR4-SFU03P)
Cable 10 m, PVC 6044649
(TR4-SFM10P)
6044652
(TR4-SFU10P)
Cable with M12 plug, 8-pin 6044650
(TR4-SFM01C)
6044653
(TR4-SFU01C)
Cable with M12 plug, 5-pin 6034591
(TR4-SFM02C)
6036678
(TR4-SFU02C)
10.2 Replacement actuators
Part number
(type code)
Replacement actuator
Multicoded Unique Coded
Actuators for sensor TR4-SDxxxx 5325631
(TR4-RDM000)
5325632
(TR4-RDU000)
Actuators for sensors TR4-SExxxx
and TR4-SFxxxx
5325633
(TR4-RFM000)
5325634
(TR4-RFU000)
10.3 Accessories
Part Part number
(type code)
T-piece for the series connection of
TR4 Direct
5325889
(TR4-AK004C)
End plug for series connection
in conjunction with T-piece
TR4-AK004C
5325890
(TR4-AL002C)
Tab. 9: Part numbers
TR4-SFxxxx safety
switches
Tab. 10: Part numbers
replacement actuators
Tab. 11: Part numbers
accessories

SICK TR4 Specifications

General

Number of Safe Outputs	2
Output Type	PNP
Protection Rating	IP67
Type	Safety Switch
Housing Material	Plastic
Supply Voltage	24V DC
Connection Type	Cable
Operating Voltage	24 V DC
Operating Temperature	-25 °C ... +70 °C
Actuator Type	Separate actuator (TR4 Direct, TR4 Standard, TR4 Extended)
