Chapitre 9 Notice d’instructions
TR4
202 © SICK AG • Industrial Safety Systems • Allemagne • Tous droits réservés 8014467/YTD7/2016-03-30
Sujet à modification sans préavis
Caractéristiques
techniques
fr
9.3.2 Schéma coté du transpondeur TR4 Direct
Fig. 17 : Schéma coté
du transpondeur TR4
Direct (mm)
24,99 20,65 18,54
88,14
10,66
7,11
6,78
4,57
⊕
5,08
4,57
68,31
72,9
77,98

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SICK TR4 and is the answer not in the manual?

SICK TR4 Specifications

General IconGeneral
Number of Safe Outputs2
Output TypePNP
Protection RatingIP67
TypeSafety Switch
Housing MaterialPlastic
Supply Voltage24V DC
Connection TypeCable
Operating Voltage24 V DC
Operating Temperature-25 °C ... +70 °C
Actuator TypeSeparate actuator (TR4 Direct, TR4 Standard, TR4 Extended)
