Chapter 10 Operating Instructions
TR4
102 © SICK AG • Industrial Safety Systems • Germany • All rights reserved 8014467/YTD7/2016-03-30
Subject to change without notice
Ordering information
en
Part Part number
(type code)
Flexi Soft safety controller
CPU0 main module 1043783
(FX3-CPU000000)
CPU1 main module 1043784
(FX3-CPU130002)
Input/output extension module 1044125
(FX3-XTIO84002)
Input expansion unit 1044124
(FX3-XTDI80002)
System plug 1043700
(FX3-MPL000001)
Safe sensor cascade Flexi Loop
Flexi Loop node with M12 female
connector, 5-pin
1061709
(FLN-OSSD1000105)
Flexi Loop node with M12 female
connector, 8-pin
1061710
(FLN-OSSD1000108)
