Siemens CU240B-2 - Standard Drive Control

Commissioning
5.4 Quick commissioning with a PC.
Converter with the CU240B-2 and CU240E-2 Control Units
154 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
5.4.4.2
Standard Drive Control
Procedure for application class [1]: Standard Drive Control
2.
Select the I/O configuration to preassign the inver
ter interfaces.
Default settings of the CU240B-2 interfaces (Page 97)
Default settings of the CU240E-2 interfaces (Page 104)
3.
Set the applicable motor standard and the inverter supply voltage.
4.
Select your motor.
5.
Enter the motor data according to the rating plate of your motor.
If you have selected a motor based on its arti
cle number, the data has
already been entered.
6.
Set the most important parameters to suit your application.
7.
Select the application:
•
[0] Constant load: Typical applications include conveyor drives
•
[1] Speed-dependent load: Typical applications include pumps and
fans
Motor identification:
•
[1]: Recommended setting. Measure the motor data at standstill and
with the motor rotating. The inverter switches off the motor after the
motor data identification has been completed.
•
[2]: Measure the motor data at standstill. The inverter switches off
the motor after the motor data identification has been completed.
Select this setting if the motor cannot freely rotate, e.g. for a
mechanically limited traversing range.
•
[3]: Measure the motor data while it is rotating. The inverter switches
off the motor after the motor data identification has been completed.
•
[11]: The same setting as [1]. The motor accelerates to the currently
set setpoint after the motor data identification.
•
[12]: The same setting as [2]. The motor accelerates to the currently
set setpoint after the motor data identification.
You have completed quick commissioning.
