Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
438 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
10.3.1.4
General data, PM240-2 - 400 V
Property
Version
Line voltage
FSA … FSC
380 V480 V 3-ph. AC ± 10 %
FSD … FSF
3 AC 380 V … 480 V -20 %, +10 %
Output voltage
3 AC 0 V … 0.95 x input voltage (max.)
Input frequency
50 Hz … 60 Hz, ± 3 Hz
Output frequency
0 … 550 Hz, depending on the control mode
Line impedance FSA … FSC
FSD … FSF
Uk ≥ 1 %, for lower values, we recommend a line reactor, or a Power Module
with the next higher power rating.
Line reactor not required
Power factor λ FSA … FSC
FSD … FSF
0.7 without line reactor for Uk ≥ 1 %
0.85 with line reactor for Uk < 1 %
0.95 line reactor not required
Inrush current
< LO base load input current
Overvoltage category acc.
to EN 60664-1
The inverter insulation is designed for surge voltages according to overvoltage Category III.
Pulse frequency Factory setting
4 kHz for devices with an LO base load power < 75 kW
2 kHz for devices with an LO base load power 75 kW
Can be adjusted in 2 kHz steps as follows:
2 kHz … 16 kHz for devices with an LO base load power < 55 kW
2 kHz … 8 kHz for devices with an LO base load power 55 kW
If you increase the pulse frequency, the inverter reduces the maximum output current.
Short-circuit current rating
(SCCR)
FSA … FSC ≤ 100 kA rms
FSD … FSF ≤ 65 kA rms
Branch protection and short-circuit strength according to UL and IEC
(https://support.industry.siemens.com/cs/ww/en/view/109479152)
Electromagnetic compati-
bility according to IEC/EN
61800-3
Devices with integrated filter are suitable for Category C2 environments.
Braking methods
DC braking, compound braking, dynamic braking with integrated braking chopper
Degree of protection ac-
cording to EN 60529
Chassis de-
vices
PT devices
IP20
IP20,
IP54
Must be installed in a control cabinet
Must be installed in a control cabinet
at the control cabinet panel
Ambient temperature FSA … FSC:
LO base load power without derating:
HO base load power without derating:
LO/HO base load power with derating:
-10 °C +40 °C
-10 °C +50 °C
-10 °C+ 60° C
FSD … FSF:
LO base load power without derating:
HO base load power without derating:
LO/HO base load power with derating:
-20 °C +40 °C
-20 °C +50 °C
-20 °C+ 60° C
Power-dependent data, PM240-2 - 600 V (Page 448)
For the maximum permissible ambient temperature, also observe the permissible ambient
temperatures for the Control Unit and possibly operator panel (IOP or BOP-2) .
