Siemens CU240B-2 - Power-Dependent Data, PM240-2 - 400 V

Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
440 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
10.3.1.5
Power-dependent data, PM240-2 - 400 V
The fuses listed in the following tables are examples of suitable fuses.
Additional components for branch protection:
Branch protection and short-circuit
strength according to UL and IEC
(https://support.industry.siemens.com/cs/ww/en/view/109479152)
Table 10- 11 PM240-2, IP20, frame sizes A, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3210…
6SL3210…
…1PE11-8UL1
…1PE11-8AL1
…1PE12-3UL1
…1PE12-3AL1
…1PE13-2UL1
…1PE13-2AL1
LO base load power
LO base load input current
LO base load output current
0.55 kW
2.3 A
1.7 A
0.75 kW
2.9 A
2.2 A
1.1 kW
4.1 A
3.1 A
HO base load power
HO base load input current
HO base load output current
0.37 kW
2.0 A
1.3 A
0.55 kW
2.6 A
1.7 A
0.75 kW
3.3 A
2.2 A
Fuse according to IEC
Fuse according to UL
3NA3 804 (4 A)
10 A Class J
3NA3 804 (4 A)
10 A Class J
3NA3 801 (6 A)
15 A Class J
Power loss
0.04 kW
0.04 kW
0.04 kW
Required cooling air flow
5 l/s
5 l/s
5 l/s
Weight without filter
Weight with filter
1.3 kg
1.5 kg
1.3 kg
1.5 kg
1.3 kg
1.5 kg
Table 10- 12 PM240-2, IP20, frame sizes A, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3210…
6SL3210…
…1PE14-3UL1
…1PE14-3AL1
…1PE16-1UL1
…1PE16-1AL1
…1PE18-0UL1
…1PE18-0AL1
LO base load power
LO base load input current
LO base load output current
1.5 kW
5.5 A
4.1 A
2.2 kW
7.7 A
5.9 A
3.0 kW
10.1 A
7.7 A
HO base load power
HO base load input current
HO base load output current
1.1 kW
4.7 A
3.1 A
1.5 kW
6.1 A
4.1 A
2.2 kW
8.8 A
5.9 A
Fuse according to IEC
Fuse according to UL
3NA3 803 (10 A)
20 A Class J
3NA3 803 (10 A)
30 A Class J
3NA3 805 (16 A)
30 A Class J
Power loss 0.07 kW 0.1 kW 0.12 kW
Required cooling air flow 5 l/s 5 l/s 5 l/s
Weight without filter
Weight with filter
1.4 kg
1.6 kg
1.4 kg
1.6 kg
1.4 kg
1.6 kg
