Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
441
Table 10- 13 PM240-2, PT, frame sizes A, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3211…
6SL3211…
…1PE18-0UL1
…1PE18-0AL1
LO base load power
LO base load input current
LO base load output current
3.0 kW
10.1 A
7.7 A
HO base load power
HO base load input current
HO base load output current
2.2 kW
8.8 A
5.9 A
Fuse according to IEC
Fuse according to UL
3NA3 805 (16 A)
30 A Class J
Power loss without filter
0.12 kW
1)
Required cooling air flow
7 l/s
Weight without filter
Weight with filter
1.8 kg
2.0 kg
1) approx. 0.1 kW through the heatsink
Table 10- 14 PM240-2, IP20, frame sizes B, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3210…
6SL3210…
…1PE21-1UL0
…1PE21-1AL0
…1PE21-4UL0
…1PE21-4AL0
…1PE21-8UL0
…1PE21-8AL0
LO base load power
LO base load input current
LO base load output current
4.0 kW
13.3 A
10.2 A
5.5 kW
17.2 A
13.2 A
7.5 kW
22.2 A
18.0 A
HO base load power
HO base load input current
HO base load output current
3.0 kW
11.6 A
7.7 A
4.0 kW
15.3 A
10.2 A
5.5 kW
19.8 A
13.2 A
Fuse according to IEC
Fuse according to UL
3NE 1814-0 (20 A)
35 A Class J
3NE 1815-0 (25 A)
35 A Class J
3NE 1803-0 (35 A)
35 A Class J
Power loss 0.11 kW 0.15 kW 0.2 kW
Required cooling air flow 9.2 l/s 9.2 l/s 9.2 l/s
Weight without filter
Weight with filter
2.9 kg
3.1 kg
2.9 kg
3.1 kg
3.0 kg
3.2 kg
