Siemens CU240B-2 - Power-Dependent Data, PM240-2 - 200 V

Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
432 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
10.3.1.3
Power-dependent data, PM240-2 - 200 V
The fuses listed in the following tables are examples of suitable fuses.
Additional components for branch protection:
Branch protection and short-circuit
strength according to UL and IEC
(https://support.industry.siemens.com/cs/ww/en/view/109479152)
Table 10- 1 PM240-2, IP20, frame sizes A, 1 AC / 3 AC 200 V … 240 V
Article No. - without filter
Article No. - with filter
6SL3210…
6SL3210…
…1PB13-0UL0
…1PB13-0AL0
…1PB13-8UL0
…1PB13-8AL0
LO base load power
LO base load input current 1 AC
LO base load input current 3 AC
LO base load output current
0.55 kW
7.5 A
4.2 A
3.2 A
0.75 kW
9.6 A
5.5 A
4.2 A
HO base load power
HO base load input current 1 AC
HO base load input current 3 AC
HO base load output current
0.37 kW
6.6 A
3.0 A
2.3 A
0.55 kW
8.4 A
4.2 A
3.2 A
Fuse according to IEC
Fuse according to UL
3NA3 803 (10 A)
15 A Class J
3NA3 805 (16 A)
15 A Class J
Power losses without filter
Power losses with filter
0.04 kW
0.04 kW
0.04 kW
0.04 kW
Required cooling air flow
5 l/s
5 l/s
Weight without filter
Weight with filter
1.4 kg
1.6 kg
1.4 kg
1.6 kg
Table 10- 2 PM240-2, PT, frame sizes A, 1 AC / 3 AC 200 V … 240 V
Article No. - without filter
Article No. - with filter
6SL3211…
6SL3211…
…1PB13-8UL0
…1PB13-8AL0
LO base load power
LO base load input current 1 AC
LO base load input current 3 AC
LO base load output current
0.75 kW
9.6 A
5.5 A
4.2 A
HO base load power
HO base load input current 1 AC
HO base load input current 3 AC
HO base load output current
0.55 kW
8.4 A
4.2 A
3.2 A
Fuse according to IEC
Fuse according to UL
3NA3 805 (16 A)
15 A Class J
Power losses without filter
Power losses with filter
0.04 kW
0.04 kW
Required cooling air flow 5 l/s
Weight without filter
Weight with filter
1.8 kg
2.0 kg
