Siemens CU240B-2 - Machine Documentation; A.7.2 Machine Documentation

Appendix
A.7 Acceptance tests for the safety functions
Converter with the CU240B-2 and CU240E-2 Control Units
504 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
A.7.2
Machine documentation
Machine or plant description
Designation
…
Type
…
Serial number
…
Manufacturer
…
End customer
…
Block diagram of the machine and/or plant:
…
…
…
…
…
…
…
Inverter data
Table A- 14 Hardware version of the safety-related inverter
Labeling the drive
Article number and hardware version of the inverter
…
…
…
…
Function table
Table A- 15 Active safety functions depending on the operating mode and safety equipment
Operating mode
Safety equipment
Drive
Selected safety function
Checked
…
…
…
…
…
…
…
…
Example:
Automatic
Protective door closed
Conveyor belt
---
---
Protective door open
Conveyor belt
STO
Emergency Stop button
pressed
Conveyor belt STO
