Installing
4.4 Installing Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
62 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
4.4.2
Dimensioned drawings, drilling dimensions for the PM240-2 Power Module,
IP20
The following dimensioned drawings and drilling patterns are not to scale.
Table 4- 1 Mounting dimensions
Frame size
Width
1)
(mm)
Height (mm)
Depth (mm)
Total
Shield plate
at the top
Power
Module
Shield plate at
the bottom
FSA
73
276
---
196
80
165
FSB
100
370
---
292
78
165
FSC 140 432 --- 355 77 165
FSD
200
707.5
83.5
472
152
237
FSE 275 850 122 551 177 237
FSF
305
1107
142
708
257
357
1)
The Power Modules can be mounted and operated side-by-side. For tolerance reasons, we rec-
ommend a lateral clearance of approx. 1 mm.
