Siemens CU240B-2 - Power-Dependent Data, PM230, IP20

Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
462 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
10.3.3.2
Power-dependent data, PM230, IP20
Note
The values for Lo
w Overload (LO) are identical with those of the rated values.
Table 10- 37 PM230, IP20, frame sizes A, 3 AC 380 V … 480 V
Article No. - without filter
Article No. - with filter
6SL3210…
6SL3210…
…1NE11-3UL1
…1NE11-3AL1
…1NE11-7UL1
…1NE11-7AL1
…1NE12-2UL1
…1NE12-2AL1
LO base load power
LO base load input current
LO base load output current
0.37 kW
1.3 A
1.3 A
0.55 kW
1.8 A
1.7 A
0.75 kW
2.3 A
2.2 A
HO base load power
HO base load input current
HO base load output current
0.25 kW
0.9 A
0.9 A
0.37 kW
1.3 A
1.3 A
0.55 kW
1.8 A
1.7 A
Fuse according to IEC
Fuse according to UL
3NE1 813-0
AJT2 / 3NE1 813-0
3NE1 813-0
AJT4 / 3NE1 813-0
3NE1 813-0
AJT4 / 3NE1 813-0
Power loss
0.04 kW
0.04 kW
0.05 kW
Required cooling air flow
1.5 l/s
1.5 l/s
4.5 l/s
Cross section of line and motor cables 1 … 2.5 mm
2
18 … 14 AWG
1 … 2.5 mm
2
18 … 14 AWG
1 … 2.5 mm
2
18 … 14 AWG
Tightening torque for line and motor cables
0.5 Nm / 4 lbf in
0.5 Nm / 4 lbf in
0.5 Nm / 4 lbf in
Weight without filter
Weight with filter
1.4 kg
1.6 kg
1.4 kg
1.6 kg
1.4 kg
1.6 kg
Table 10- 38 PM230, IP20, frame sizes A, 3 AC 380 V … 480 V
Article No. - without filter
Article No. - with filter
6SL3210…
6SL3210…
…1NE13-1UL1
…1NE13-1AL10
…1NE14-1UL1
…1NE14-1AL1
…-1NE15-8UL1
…-1NE15-8AL1
LO base load power
LO base load input current
LO base load output current
1.1 kW
3.2 A
3.1 A
1.5 kW
4.2 A
4.1 A
2.2 kW
6.1 A
5.9 A
HO base load power
HO base load input current
HO base load output current
0.75 kW
2.3 A
2.2 A
1.1 kW
3.2 A
3.1 A
1.5 kW
4.2 A
4.1 A
Fuse according to IEC
Fuse according to UL
3NE1 813-0
AJT6 / 3NE1 813-0
3NE1 813-0
AJT6 / 3NE1 813-0
3NE1 813-0
AJT10 / 3NE1 813-0
Power loss
0.06 kW
0.07 kW
0.08 kW
Required cooling air flow
4.5 l/s
4.5 l/s
4.5 l/s
Cross section of line and motor cables 1 … 2.5 mm
2
18 … 14 AWG
1 … 2.5 mm
2
18 … 14 AWG
1.5 … 2.5 mm
2
16 … 14 AWG
Tightening torque for line and motor cables
0.5 Nm / 4 lbf in
0.5 Nm / 4 lbf in
0.5 Nm / 4 lbf in
Weight without filter
Weight with filter
1.4 kg
1.6 kg
1.4 kg
1.6 kg
1.4 kg
1.6 kg
