Backing up data and series commissioning
7.3 Saving settings and transferring them using an operator panel
Converter with the CU240B-2 and CU240E-2 Control Units
Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
367
7.3
Saving settings and transferring them using an operator panel
You can transfer the inverter settings to the Operator Panel BOP-2 or vice versa, the data
from the BOP-2 to the inverter.
Precondition
The inverter power supply has been switched on.
Inverter → BOP-2
Procedure
To back up the settings on the BOP-2, proceed as follows:
1.
Go to the menu level “OPTIONS”.
2.
In the “OPTIONS” menu, select “TO
BOP”.
3.
Start data transfer with OK.
4.
Wait until the inverter has backed up the settings to the BOP
-2.
You have backed up the settings on the BOP-2.
