Siemens CU240B-2 - Power-Dependent Data, PM250

Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
471
10.3.4.3
Power-dependent data, PM250
Note
The values for Low Overload (LO) are identical with those of the rated values.
Table 10- 49 PM250, IP20, frame sizes C, 3 AC 380 V … 480 V
Article No. - with filter
6SL3225-…
0BE25-5AA1
0BE27-5AA1
0BE31-1AA1
LO base load power
LO base load input current
LO base load output current
7.5 kW
18 A
18 A
11 kW
25 A
25 A
15 kW
32 A
32 A
HO base load power
HO base load input current
HO base load output current
5. 5 kW
13.2 A
13.2 A
7.5 kW
19 A
19 A
11 kW
26 A
26 A
Fuse
20 A, Class J
32 A, Class J
35 A, Class J
Power loss
0.24 kW
0.30 kW
0.31 kW
Required cooling air flow
38 l/s
38 l/s
38 l/s
Tightening torque for line and motor cables
2.3 Nm / 20 lbf in
2.3 Nm / 20 lbf in
2.3 Nm / 20 lbf in
Weight
7.5 kg
7.5 kg
7.5 kg
Table 10- 50 PM250, IP20, frame sizes D, 3 AC 380 V … 480 V
Article No. - with filter
6SL3225-…
0BE31-5AA0
0BE31-8AA0
0BE32-2AA0
LO base load power
LO base load input current
LO base load output current
18.5 kW
36 A
38 A
22 kW
42 A
45 A
30 kW
56 A
60 A
HO base load power
HO base load input current
HO base load output current
15 kW
30 A
32 A
18.5 kW
36 A
38 A
22 kW
42 A
45 A
Fuse according to IEC
Fuse according to UL
3NA3820
50 A, Class J
3NE1817-0
3NA3822
63 A, Class J
3NE1818-0
3NA3824
80 A, Class J
3NE1820-0
Power loss
0.44 kW
0.55 kW
0.72 kW
Required cooling air flow
22 l/s
22 l/s
39 l/s
Tightening torque for line and motor cables
6 Nm / 53 lbf in
6 Nm / 53 lbf in
6 Nm / 53 lbf in
Weight
15 kg
15 kg
16 kg
