Siemens CU240B-2 - Power-Dependent Data, PM240

Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
454 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
10.3.2.2
Power-dependent data, PM240
Note
The given
input currents are valid for operation without a line reactor for a line voltage of 400
V with Vk = 1 % referred to the rated power of the inverter. If a line reactor is used, the
specified values are reduced by a few percent.
Note
The values for L
ow Overload (LO) are identical with those of the rated values.
Table 10- 28 PM240, IP20, frame sizes A, 3-phase 380 … 480 VAC
Article no. - without filter
6SL3224-…
…0BE13-7UA0
…0BE15-5UA0
…0BE17-5UA0
LO base load power
LO base load input current
LO base load output current
0.37 kW
1.6 A
1.3 A
0.55 kW
2.0 A
1.7 A
0.75 kW
2.5 A
2.2 A
HO base load power
HO base load input current
HO base load output current
0.37 kW
1.6 A
1.3 A
0.55 kW
2.0 A
1.7 A
0.75 kW
2.5 A
2.2 A
Fuse according to UL (from SIEMENS)
Fuse according to UL (Class J, K-1 or K-5)
3NE1813-0, 16 A
10 A
3NE1813-0, 16 A
10 A
3NE1813-0, 16 A
10 A
Power loss
0.097 kW
0.099 kW
0.102 kW
Required cooling air flow 4.8 l/s 4.8 l/s 4.8 l/s
Weight
1.2 kg
1.2 kg
1.2 kg
Table 10- 29 PM240, IP20, frame sizes A, 3-phase 380 … 480 VAC
Article no. - without filter
6SL3224-…
…0BE21-1UA0
…0BE21-5UA0
LO base load power
LO base load input current
LO base load output current
1.1 kW
3.9 A
3.1 A
1.5 kW
4.9 A
4.1 A
HO base load power
HO base load input current
HO base load output current
1.1 kW
3.8 A
3.1 A
1.5 kW
4.8 A
4.1 A
Fuse according to UL (from SIEMENS)
Fuse according to UL (Class J, K-1 or K-5)
3NE1813-0, 16 A
10 A
3NE1813-0, 16 A
10 A
Power loss
0.108 kW
0.114 kW
Required cooling air flow
4.8 l/s
4.8 l/s
Weight
1.1 kg
1.1 kg
