Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
455
Table 10- 30 PM240, IP20, frame sizes B, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3224-…
6SL3224-…
…0BE22-2UA0
…0BE22-2AA0
…0BE23-0UA0
…0BE23-0AA0
…0BE24-0UA0
…0BE24-0AA0
LO base load power
LO base load input current
LO base load output current
2.2 kW
7.6 A
5.9 A
3 kW
10.2 A
7.7 A
4 kW
13.4 A
10.2 A
HO base load power
HO base load input current
HO base load output current
2.2 kW
7.6 A
5.9 A
3 kW
10.2 A
7.7 A
4 kW
13.4 A
10.2 A
Fuse according to UL (from SIEMENS)
Fuse according to UL (Class J, K-1 or K-5)
3NE1813-0, 16 A
16 A
3NE1813-0, 16 A
16 A
3NE1814-0, 20 A
20 A
Power loss
0.139 kW
0.158 kW
0.183 kW
Required cooling air flow
24 l/s
24 l/s
24 l/s
Weight
4.3 kg
4.3 kg
4.3 kg
Table 10- 31 PM240, IP20, frame sizes C, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3224-…
6SL3224-…
…0BE25-5UA0
…0BE25-5AA0
…0BE27-5UA0
…0BE27-5AA0
…0BE31-1UA0
…0BE31-1AA0
LO base load power
LO base load input current
LO base load output current
7.5 kW
21.9 A
18 A
11 kW
31.5 A
25 A
15 kW
39.4 A
32 A
HO base load power
HO base load input current
HO base load output current
5.5 kW
16.7 A
13.2 A
7.5 kW
23.7 A
19 A
11 kW
32.7 A
26 A
Fuse according to UL (from SIEMENS)
Fuse according to UL (Class J, K-1 or K-5)
3NE1814-0, 20 A
20 A
3NE1814-0, 20 A
20 A
3NE1803-0, 35 A
35 A
Power loss
0.240 kW
0.297 kW
0.396 kW
Required cooling air flow 55 l/s 55 l/s 55 l/s
Weight without filter
Weight with filter
6.5 kg
7 kg
6.5 kg
7 kg
6.5 kg
7 kg
