Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
472 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
Table 10- 51 PM250, IP20, frame sizes E, 3 AC 380 V … 480 V
Article No. - with filter
6SL3225-…
0BE33-0AA0
0BE33-7AA0
LO base load power
LO base load input current
LO base load output current
37 kW
70 A
75 A
45 kW
84 A
90 A
HO base load power
HO base load input current
HO base load output current
30 kW
56 A
60 A
37 kW
70 A
75 A
Fuse according to IEC
Fuse according to UL
3NA3830
100 A, Class J
3NE1821-0
3NA3832
125 A, Class J
3NE1822-0
Power loss
1.04 kW
1.2 kW
Required cooling air flow
22 l/s
39 l/s
Tightening torque for line and motor cables
6 Nm / 53 lbf in
6 Nm / 53 lbf in
Weight
21 kg
21 kg
Table 10- 52 PM250, IP20, frame sizes F, 3 AC 380 V … 480 V
Article No. - with filter
6SL3225-…
0BE34-5AA0
0BE35-5AA0
0BE37-5AA0
LO base load power
LO base load input current
LO base load output current
55 kW
102 A
110 A
75 kW
135 A
145 A
90 kW
166 A
178 A
HO base load power
HO base load input current
HO base load output current
45 kW
84 A
90 A
55 kW
102 A
110 A
75 kW
135 A
145 A
Fuse according to IEC
Fuse according to UL
3NA3836
160 A, Class J
3NE1824-0
3NA3140
200 A, Class J
3NE1825-0
3NA3144
250 A, Class J
3NE1827-0
Power loss 1.5 kW 2.0 kW 2.4 kW
Required cooling air flow 94 l/s 94 l/s 117 l/s
Tightening torque for line and motor cables
13 Nm / 115 lbf in
13 Nm / 115 lbf in
13 Nm / 115 lbf in
Weight
51 kg
51 kg
51 kg
