Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
442 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
Table 10- 15 PM240-2, PT, frame sizes B, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3211…
6SL3211…
...1PE21-8UL0
...1PE21-8AL0
LO base load power
LO base load input current
LO base load output current
7.5 kW
22.2 A
18.0 A
HO base load power
HO base load input current
HO base load output current
5.5 kW
19.8 A
13.7 A
Fuse according to IEC
Fuse according to UL
3NE 1803-0 (35 A)
35 A Class J
Power loss
0.2 kW
1)
Required cooling air flow
9.2 l/s
Weight without filter
Weight with filter
3.6 kg
3.9 kg
1) approx. 0.16 kW through the heatsink;
Table 10- 16 PM240-2, IP20, frame sizes C, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3210…
6SL3210…
…1PE22-7UL0
…1PE22-7AL0
…1PE23-3UL0
…1PE23-3AL0
LO base load power
LO base load input current
LO base load output current
11.0 kW
32.6 A
26.0 A
15.0 kW
39.9 A
32.0 A
HO base load power
HO base load input current
HO base load output current
7.5 kW
27.0 A
18.0 A
11.0 kW
36.0 A
26.0 A
Fuse according to IEC
Fuse according to UL
3NE 1817-0 (50 A)
50 A Class J
3NE 1817-0 (50 A)
50 A Class J
Power loss 0.3 kW 0.37 kW
Required cooling air flow 18.5 l/s 18.5 l/s
Weight without filter
Weight with filter
4.7 kg
5.3 kg
4.8 kg
5.4 kg
