Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
443
Table 10- 17 PM240-2, PT, frame sizes C, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3211…
6SL3211…
...1PE23-3UL0
...1PE23-3AL0
LO base load power
LO base load input current
LO base load output current
15.0 kW
39.9 A
32.0 A
HO base load power
HO base load input current
HO base load output current
11.0 kW
36.0 A
26.0 A
Fuse according to IEC
Fuse according to UL
3NE 1817-0 (50 A)
50 A Class J
Power loss
0.37 kW
1)
Required cooling air flow
18.5 l/s
Weight without filter
Weight with filter
5.8 kg
6.3 kg
1) approx. 0.3 kW through the heatsink;
Table 10- 18 PM240-2, IP20, FSD, 3 AC 380 V … 480 V
Article No. - without filter
Article No. - with filter
6SL3210-…
6SL3210-…
…1PE23-8UL0
…1PE23-8AL0
…1PE24-5UL0
…1PE24-5AL0
…1PE26-0UL0
…1PE26-0AL0
LO base load power
LO base load input current
LO base load output current
18.5 kW
36 A
38 A
22 kW
42 A
45 A
30 kW
57 A
60 A
HO base load power
HO base load input current
HO base load output current
15 kW
33 A
32 A
18.5 kW
38 A
38 A
22 kW
47 A
45 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1 818-0 / 63 A
60 A
3NE1 820-0 / 80 A
70 A
3NE1 021-0 / 100A
90 A
Power loss without filter
Power loss with filter
0.55 kW
0.56 kW
0.68 kW
0.68 kW
0.76 kW
0.77 kW
Required cooling air flow 55 l/s 55 l/s 55 l/s
Weight without filter
Weight with filter
16 kg
17.5 kg
16 kg
17.5 kg
17 kg
18.5 kg
