Technical data
10.3 Technical data, Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
444 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
Table 10- 19 PM240-2, IP20, FSD, 3 AC 380 V … 480 V
Article No. - without filter
Article No. - with filter
6SL3210-…
6SL3210-…
…1PE27-5UL0
…1PE27-5AL0
LO base load power
LO base load input current
LO base load output current
37 kW
70 A
75 A
HO base load power
HO base load input current
HO base load output current
30 kW
62 A
60 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1 021-0 / 100 A
100 A
Power loss without filter
Power loss with filter
1.01 kW
1.02 kW
Required cooling air flow
55 l/s
Weight without filter
Weight with filter
17 kg
18.5 kg
Table 10- 20 PM240-2, IP20, FSE, 3 AC 380 V … 480 V
Article No. - without filter
Article No. - with filter
6SL3210-…
6SL3210-…
…1PE28-8UL0
…1PE28-8AL0
…1PE31-1UL0
…1PE31-1AL0
LO base load power
LO base load input current
LO base load output current
45 kW
86 A
90 A
55 kW
104 A
110 A
HO base load power
HO base load input current
HO base load output current
37 kW
78 A
75 A
45 kW
94 A
90 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1 022-0 / 125A
125 A
3NE1 224-0 / 160A
150 A
Power losses without filter
Power losses with filter
1.19 kW
1.2 kW
1.54 kW
1.55 kW
Required cooling air flow
83 l/s
83 l/s
Weight without filter
Weight with filter
26kg
28 kg
26 kg
28 kg
