Technical data

10.3 Technical data, Power Modules

Converter with the CU240B-2 and CU240E-2 Control Units

Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC

445

Table 10- 21 PM240-2, IP20, FSF, 3 AC 380 V … 480 V

Article No. - without filter

Article No. - with filter

6SL3210-…

…1PE31-5UL0

…1PE31-5AL0

…1PE31-8UL0

…1PE31-8AL0

…1PE32-1UL0

…1PE32-1AL0

LO base load power

LO base load input current

LO base load output current

75 kW

140 A

145 A

90 kW

172 A

178 A

110 kW

198 A

205 A

HO base load power

HO base load input current

HO base load output current

55 kW

117 A

110 A

75 kW

154

145 A

90 kW

189 A

178 A

Siemens fuse according to IEC/UL

Fuse according to IEC/UL, Class J

3NE1 225-0 / 200 A

200 A

3NE1 227-0 / 250 A

250 A

3NE1 230-0 / 315 A

300 A

Power loss without filter

Power loss with filter

1.95 kW

1.97 kW

2.54 kW

2.56 kW

2.36 kW

2.38 kW

Required cooling air flow

153 l/s

Weight without filter

Weight with filter

57 kg

63 kg

57 kg

63 kg

61 kg

65 kg

Table 10- 22 PM240-2, IP20, FSF, 3 AC 380 V … 480 V

Article No. - without filter

Article No. - with filter

6SL3210-…

…1PE32-5UL0

…1PE32-5AL0

LO base load power

LO base load input current

LO base load output current

132 kW

242 A

250 A

HO base load power

HO base load input current

HO base load output current

110 kW

218 A

205 A

Siemens fuse according to IEC/UL

Fuse according to IEC/UL, Class J

3NE1 331-0 / 350 A

350 A

Power loss without filter

Power loss with filter

3.09 kW

3.12 kW
