Description
3.4 Components for the Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
44 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
Sine-wave filter for PM250 Power Module
Power Module
Power
Sine-wave filter
FSC
6SL3225-0BE25-5☐A0
7.5 kW
6SL3202-0AE22-0SA0
6SL3225-0BE27-5☐ A0,
6SL3225-0BE31-1☐A0
11.0 kW … 15.0 kW 6SL3202-0AE23-3SA0
FSD 6SL3225-0BE31-5☐A0,
6SL3225-0BE31-8☐A0
18.5 kW … 22 kW 6SL3202-0AE24-6SA0
6SL3225-0BE32-2☐A0
30 kW
6SL3202-0AE26-2SA0
FSE 6SL3225-0BE33-0☐A0,
6SL3225-0BE33-7☐A0
37 kW … 45 kW 6SL3202-0AE28-8SA0
FSF 6SL3225-0BE34-5☐A0,
6SL3225-0BE35-5☐A0
55 kW … 75 kW 6SL3202-0AE31-5SA0
6SL3225-0BE37-5☐A0
90 kW
6SL3202-0AE31-8SA0
