Description
3.4 Components for the Power Modules
Converter with the CU240B-2 and CU240E-2 Control Units
46 Operating Instructions, 01/2016, FW V4.7 SP6, A5E34259001B AC
Braking resistors for PM240-2, 200 V
Power Module
Power
Braking resistor
FSA 6SL3210-1PB13-0❒L0,
6SL321❒-1PB13-8❒L0
0.55 kW … 0.75 kW JJY:023146720008
FSB 6SL3210-1PB15-5❒L0,
6SL3210-1PB17-4❒L0,
6SL321❒-1PB21-0❒L0
1.1 kW … 2.2 kW JJY:023151720007
FSC 6SL3210-1PB21-4❒L0,
6SL321❒-1PB21-8❒L0
3 kW … 4 kW JJY:02 3163720018
6SL3210-1PC22-2❒L0,
6SL3210-1PC22-8❒L0
5.5 kW … 7.5 kW JJY:023433720001
FSD 6SL3210-1PC24-2UL0,
6SL3210-1PC25-4UL0,
6SL3210-1PC26-8UL0
11 kW … 18.5 kW JJY:023422620002
FSE 6SL3210-1PC28-0UL0,
6SL3210-1PC31-1UL0
22 kW … 30 kW JJY:023423320001
FSF 6SL3210-1PC31-3UL0,
6SL3210-1PC31-6UL0,
6SL3210-1PC31-8UL0
37 kW … 55 kW JJY:023434020003
Braking resistors for PM240-2, 400 V
Power Module
Power
Braking resistor
FSA 6SL3210-1PE11-8❒L1,
6SL3210-1PE12-3❒L1,
6SL3210-1PE13-2❒L1,
6SL3210-1PE14-3❒L1
0.55 kW … 1.5 kW 6SL3201-0BE14-3AA0
6SL321❒-1PE16-1❒L1,
6SL321❒-1PE18-0❒L1
2.2 kW … 3.0 kW 6SL3201-0BE21-0AA0
FSB 6SL3210-1PE21-1❒L0,
6SL3210-1PE21-4❒L0,
6SL321❒-1PE21-8❒L0
4 kW … 7.5 kW 6SL3201-0BE21-8AA0
FSC 6SL3210-1PE22-7❒L0,
6SL321❒-1PE23-3❒L0
11 kW … 15 kW 6SL3201-0BE23-8AA0
FSD 6SL3210-1PE23-8❒L0,
6SL3210-1PE24-5❒L0
18.5 kW … 22 kW JJY:023422620001
6SL3210-1PE26-0❒L0,
6SL3210-1PE27-5❒L0
30 kW … 37 kW JJY:023424020001
FSE 6SL3210-1PE28-8❒L0,
6SL3210-1PE31-1❒L0
45 kW … 55 kW JJY:023434020001
FSF 6SL3210-1PE31-5❒L0,
6SL3210-1PE31-8❒L0,
75 kW … 90 kW JJY:023454020001
6SL3210-1PE32-1❒L0,
6SL3210-1PE32-5❒L0
90 kW … 132 kW JJY:023464020001
