Siemens CU240B-2 User Manual

2-493© Siemens AG 2011 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 01/2011
Function diagrams 2
Contents
2.1 Contents: function diagrams 2-494
2.2 Explanations for the function diagrams 2-499
2.3 Overview 2-504
2.4 Input/Output Terminals 2-512
2.5 Communication 2-520
2.6 Internal control/status words 2-549
2.7 Setpoint channel 2-567
2.8 V/f control 2-577
2.9 Vector control 2-581
2.10 Free Function Blocks 2-601
2.11 Technology functions 2-622
2.12 Technology controller 2-630
2.13 Signals and monitoring functions 2-635
2.14 Faults and warnings 2-645
2.15 Data sets 2-650
