Tag Detail3-10 SIMATIC PCS 7 OSx 4.1.2 Operator
Tag Group Displays (continued)
Figure 3-8 shows an example of a tag group as it appears in the Operate
state. Note that the configuration engineer has assigned only six tags to this
group. The operator can display the tag detail for the tag by selecting a
Detail button.
NOTE: If the operator displays a command form for one of the faceplates,
makes a change to a field, and the change does not succeed, the value in the
database does not change. However, the command form displays the new
value that the operator attempted to enter. The tag faceplate continues to
display the correct, unchanged value. When the operator redisplays the
command form, it contains the original, unchanged value.
Figure 3-8 Tag Group Display
