Action Requests 7-9SIMATIC PCS 7 OSx 4.1.2 Operator
With the system in Operate state, the operator can answer action requests
after they are triggered.
To respond to an action request, follow these steps.
1. Click the action request icon. The screen displays the Action Request
Summary dialog box in the lower left part of the screen (Figure 7-5).
fmacsumm: Action Request Summary
REACTOR 27W IS EMPTY AND AVAILABLE FOR USE. CONSULT THE
DAILY PRODUCTION PLAN TO DETERMINE WHICH REAGENT NEEDS
TO BE PRODUCED NEXT.
Comment:
BATCH_SELEC 19--AUG 11:07:14
User ID:
Batch ID:
1of1
REAGENT_147
REAGENT_64
REAGENT_39
URGENT
?
Urgent
View Commit
Dismiss
Figure 7-5 Responding to an Action Request
2. Select an action request entry and respond with the appropriate
answer. The left and right arrow buttons allow the operator to access
other action requests. The action request package allows the operator
to define five types of requests.
• The Multi-Choice request consists of up to four different answers,
from which the operator chooses one.
• The Enter Value request prompts the operator to enter a new
value for a particular tag attribute.
• The Acknowledge request asks the operator to acknowledge that a
request occurred.
• The View request answers itself automatically when the operator
displays it on the screen.
• The Event Log request does not turn on the action request icon.
However, it does send a message to the system log when triggered.
Responding to an
Action Request
