OSx Station Control 2-5SIMATIC PCS 7 OSx 4.1.2 Operator
If an OSx station line entry in the Network Status or Network Setup dialog
boxes is highlighted with a magenta background, the station is no longer an
active station (Figure 2-3). This happens when either the network or the
OSx station fails. An inactive OSx station is not the same as a station that
you have set to out_of_service.
If an OSx station line entry is highlighted with a yellow background, the
station is no longer syn chronized with the primary.
If an OSx station line entry is highlighted with a cyan (light blue)
background, the station is in the process o f synchronizing with the primary.
To resynchronize remote stations, use the
Re_Sync command from Network
Setup (Figure 2-1).
Magenta= Station is not active.
Yellow = Station is out of sync.
Cyan = Station is synchronizing.
Network Status
Operations Stations
Name Description State
Control Nodes
Name Description State
Role
Main
Network
Alternate
Network
Connection
Type
Main
Connection
Alternate
Connection
Controller
Type
Connection
Type
scot21 Host Supervisotry OPERATE PRIMARY_ROLE ACTIVE ACTIVE SUPERVISORY
C2 UNKNOWN UNAVAILABLE
555_1102
UNAVAILABLE
505 Media 2 & 1, Redundant CP1434
scot33 OPERATE NORMAL_ROLE UNAVAILABLE UNAVAILABLE OPERAT OR
OK View... Cancel Help
Figure 2-3 OSx Station Status
