OSx Station Basics1-44 SIMATIC PCS 7 OSx 4.1.2 Operator
Identifying Screen Areas (continued)
Short-List Display Tool Place the cursor on the field adjacent to a
short-list display tool and click the right button to display a list of items
thatcanbeusedinthefield(Figure 1-15). After the list is displayed, the
operator can select an item by clicking on the item.
Right click the field
adjacent to the
short-list display
tool...
... and list is displayed.
Left click the
item...
... and item is
placed in the field.
Figure 1-15 Displaying a Short List of Ite ms
NOTE: You can select items on the short-list and long-list display tools and
then use the scroll bar to locate other items in the list. Items that you have
selected can scroll off the list and remain selected. Any operations that you
execute on selected items affect all selected items, including those not
currently showing on the list.
