Action Requests7-8 SIMATIC PCS 7 OSx 4.1.2 Operator
Responding to Action Requests (continued)
The following two fields appear only when the action request is the Enter
Value type : Last Value and New Value. Figure 7-3 showsanActionRequest
Summary for an Enter Value request.
Last Value LastvalueoftheanswerattributefortheEnterValueanswer
type.
New Value The new value entered for the answer attribute of the Enter
Value answer typ e.
REACTOR 27W IS FULL AND READY TO START. ENTER THE
CORRECT SOAK TEMPERATURE FOR THE BATCH BEING PRODUCED.
CONSULT THE DAILY PRODUCTION PLAN.
Comment:
User ID:
1of1
fmacsumm: Action Request Summary
URGENT
Last Value:
New Value:
0
View Commit Dismiss
Batch ID:
BATCH_SELECT 19--AUG 11:07:14
Figure 7-3 Action Request Summary for Enter Value
Choices When the action request is the Multi-Choice type, four radio
buttons with the available choices are displayed at the lower left of the
Action Request Summary. Buttons that have no choices configured are
grayed out. Figure 7-4 showsanActionRequestSummaryfora
Multi-Choice request.
REACTOR 27W IS EMPTY AND AVAILABLE FOR USE. CONSULT THE
DAILY PRODUCTION PLAN TO DETERMINE WHICH REAGENT NEEDS
TO BE PRODUCED NEXT.
Comment:
BATCH_SELECT 19--AUG 11:07:14
Batch ID:
1of1
REAGENT_147
REAGENT_64
REAGENT_39
fmacsumm: Action Request Summary
URGENT
View Commit Dismiss
User ID:
Figure 7-4 Action Request Summary for Multi-Choice
