Function diagram
87654321
fp_mc_391_e.vsd
Current controller motor parameters
MASTERDRIVES MC
14.10.10
-391 -
V2.5
Select Mot Type
0 ... 4
P095 (1)
Select1FT6/1FK6
0 ... 253
P096 (0)
Select1PH7
0 ... 253
P097 (0)
Mot Rtd Volts
100 ... 1000 V
P101 (400)
Mot No Load Amps
0.00 ... 1300 A
P103 (~)
MotPwrFactor
0.500 ... 0.990
P104 (~)
Mot Rtd Freq
10.0 ... 400.0 Hz
P107 (50)
Mot Rtd Speed
0 ... 12000 1/min
P108 (3000)
Motor #PolePairs
1 ... 66
P109 (2)
Ls = f(isd)
0.1...6553.5 %
P111.1 to .10
P095 Select Mot Type:
0 No motor selected
1 1FT6/1FK6
2 1PA6/1PL6/1PH4/1PH7
3 Synchronous motor, general
4 Induction motor, general
5 1FW3
Mot Rtd Torque
0.00...6535.00 Nm
P113 (~)
Mot Rtd Amps
0.00 ... 1300 A
P102 (~)
Mot.ShCirCurrent
0.00 ... 600.00 A
P105 (0.00)
Main Field Induc
0.0 ... 2000.0 mH
P120 (~)
Stator Resist
0 ... 50000 m
P121 (~)
Tot Leak React
0 ... 65535 m
P122 (~)
Stator React
0.00 ... 655.00
P123 (~)
Rotor TimeConst
0 ... 10000 ms
P124 (~)
Select MotEncod
1 ... 7
P130 [500]
Ratio Lq/Ld
0.2 ... 5.0
P119 (~)
1FW3
Transmission ratio
1/110 ... 110/1 Nm
P116
Select 1FW3
0 ... 13
P099 (0)
Kp-Adaption
0.00 ... 1300 A
P117.1 to .2
