Siemens simovert masterdrives

-782 -
Function diagram
87654321
fp_mc_782_e.vsd
Free blocks
MASTERDRIVES MC
02.02.04
Pulse generator, sampling time changers
V2.5
1
1
1
1
1
1
The block does not have any logic function.
It only transfers a digital signal consistently from
a faster sampling time to a slower one.
The block ensures that the signal has the same
value in the slow sampling time for all
"consumers" (signal sinks).
Note:
multiple of (2 x sampling time).
Example:
Tp = 10 ms
The implemented period Tp is always an integral
Tab = 3.2 ms
Implemented period = 6.4 ms
Sampling ratio 1:1
Tp
Max. output frequency
1/(2 x sampling time)
1 Pulse generator (flash encoder) {3 µs / 8 µs if Tp is changed} 6 sampling time changers for control signals {1 µs}
B
U404.03 (0)
U950.68 = __ (20)
B0572
B
U404.06 (0)
U950.71 = __ (20)
B0575
B
U404.05 (0)
U950.70 = __ (20)
B0574
B
U404.04 (0)
U950.69 = __ (20)
B0573B
U404.01 (0)
U950.66 = __ (20)
B0570
B
U404.02 (0)
U950.67 = __ (20)
B0571
U950.65 = __ (20)
B0576
K
U407 (613)
K0613
Period Tp
0 … 60000 ms
U435 (0)
