Parameter
Description Data Read/write
U675*
Rel_Correction
2675
INDEX 1:
Binector source for the enable of referencing of
U660.1 -> B0824 Fixed binectors
INDEX 2:
Binector source for the enable of position correction of
U660.2 -> B0825 Fixed binectors
INDEX 3:
Binector source for deleting the remaining distance during
position correction.
index1: 824
Unit: -
Indices: 3
Type: L2 ,B
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U676*
MastSetpSync
2676
0->1 : Synchronization with positive edge Init: 0
Unit: -
Indices: -
Type: L2 ,B
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U677*
DispAngle_abs
2677
Displacement angle input [LU]
Index 1:
Displacement angle absolute
Index 2:
Displacement angle relative
index1: 0
Min: -
2147483648
Max:
2147483647
Unit: -
Indices: 2
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U678*
DisplaceAngle
2678
Index 1: Displacement angle absolute
Index 2: Displacement angle setting value
Index 3: Displacement angle relative
index1: 813
Unit: -
Indices: 3
Type: L2 ,K
,K
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U679
VsetVirtMastFix
2679
Fixed setpoint for the virtual master axis in 10 LU/min at
KK818 -> U680 (default)
Init: 0
Min: -
2147483647
Max:
2147483647
Unit: -
Indices: -
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U680*
S.SpdSetp VMAx
2680
Source of the speed setpoint of the virtual master axis if
this is to be specified in [10*LU/min].
Function diagram [832.1]
Init: 818
Unit: -
Indices: -
Type: L2 ,K
,K
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U681*
S.V set % VMAx
2681
Source of the speed setpoint of the virtual master axis if it
is to be specified in %. For this, the speed which should
correspond to the 100% value must be indicated in
increments/sec in U682.
Function diagram [832.1]
Init: 0
Unit: -
Indices: -
Type: L2 ,K
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
