Parameter
Description Data Read/write
U682*
Vrated VmAxis
2682
Rated master speed of the virtual master axis.
The value indicates which speed in [10*LU/min] should
correspond to the 100% input value at U681. The value
must only be indicated, if the master speed is specified in
[%] (U683=0) or the connector KK0820 is used.
Function diagram 832.2
Init: 1228800
Min: 1
Max:
2147483647
Unit: -
Indices: -
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U683*
Vset (inc/s)(%)
2683
The parameter selects the source for the speed setpoint
of the virtual master axis from:
0 = Specified in [%] via U681
1 = Specified in [I10*LU/min] via U680
Function diagram [832.3]
Init: 0
Min: 0
Max: 1
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U684*
S.CtrlSig VMAx
2684
The parameter defines the source for the control signals
of the virtual master axis
Index 1: [R:VM] Reset (V=0)
Index 2: [ST_VM] Start/Stop (1= Start acceleration)
Index 3: [S_VM] Set virtual master axis to initial position
Function diagram [832.2]
index1: 0
Unit: -
Indices: 3
Type: L2 ,B
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U685*
Accel VMAx
2685
Acceleration and deceleration of the ramp-function
generator in the virtual master axis. Acceleration is
specified in [100*LU/s^2].
Function diagram [832.5]
Init: 204
Min: 0
Max:
2147483647
Unit: -
Indices: -
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U686*
S.SetV VMAx
2686
BICO parameter for selecting the connector for the setting
value of the virtual master axis.
In function diagram 832.5
Init: 819
Unit: -
Indices: -
Type: L2 ,K
,K
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U687*
Axis Cycle VMAx
2687
Axis cycle length of the virtual master axis [LU].
Function diagram [832.6]
Init: 4096
Min: 0
Max:
2147483647
Unit: -
Indices: -
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U688*
SetpFixConnCatch
2688
Setpoints of the loops over fixed connectors
Index 1: Stopping position of the loop
Index 2: Speed setpoint of the loop
index1: 0
Min: -
2147483648
Max:
2147483647
Unit: -
Indices: 2
Type: I4
Menus:
- Parameter menu
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U689*
S.Rel VMAx
2689
Parameter selects the binector for enabling the virtual
master axis. If the enable signal is 0, the master axis is
not calculated.
Function diagram [832.2]
Init: 1
Unit: -
Indices: -
Type: L2 ,B
Menus:
- Parameter menu
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
