Siemens simovert masterdrives

Parameter
Description Data Read/write
U879
BPos RefWindow
2879
Basic positioner homing position acquisition, window
widths.
Window active when homing position acquired for the first
time (B0888= HIGH)
Index 1: Inner window
Index 2: Outer window
In function diagram 789c.1
index1: 0
Min: -
2147483647
Max:
2147483647
Unit: -
Indices: 2
Type: I4
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U880*
BPos Smooth
2880
Smoothing time for basic positioning.
Acts on speed setpoint KK0881
and position setpoint KK0882
In function diagram 789c.3
Init: 0,000
Min: 0,000
Max: 10,000
Unit: s
Indices: -
Type: O2
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U881*
S.BPos Pt1 Adapt
2881
Source for PT1 adaption of the rounding time of U880
0...10.000(s) in percent.
The input value of 0...200% is multiplied by the time
0...10.000(s).
In function diagram 789c.2
Init: 1
Unit: -
Indices: -
Type: L2 ,K
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U882*
Reset SET-SETP
2882
RESET SET-SETPOINT
Input of the SET SETPOINT transfer block [788a].
This input is effective in addition to or linked to POWER
ON.
The RESET has a static action. LOW => RESET=> y=0
(all valid output values of the set setpoint transfer are
reset).
In function diagram 789a.5
Init: 1
Unit: -
Indices: -
Type: L2 ,B
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U883
BPos REL MOD
2883
Basic positioner
Positioning mode for relative:
0 : In the case of relative positioning POS_TYP_ACT=1),
the content of the position value of source U850.2 is used.
Meaning:
In the case of homing on the fly, the corrected setpoint is
calculated in with the travel distance (SET=ACTUAL)
Note:
The correction is performed in the most direct possible
way. Meaning: Direction reversal possible.
1 : In the case of relative positioning (POS_TYP_ACT=1),
the internal position value S_pos (KK871) is used.
Meaning:
In the case of homing on the fly, the corrected setpoint is
not calculated in with the travel distance (SET<>ACTUAL)
Note:
The software limit switches no longer refer to the actual
value of the measuring system.
In function diagram 789b.1
Init: 0
Min: 0
Max: 1
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
n884
BPos DIAG
2884
Visualization parameter for diagnostics Dec.Plc.: 0
Unit: -
Indices: 4
Type: I4
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
246
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
