Siemens simovert masterdrives

Parameter
Description Data Read/write
U885*
Src SyncLocal ON
2885
Switch setpoint input U886 in synchronism branch Init:
Unit: -
Indices: -
Type: L2 ,B
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U886*
Src SyncLocal
2886
Engagable offset distance prior to generation of the
position setpoint
Index 1: Offset distance
Index 2: Offset speed
index1: 0
Unit: -
Indices: 2
Type: L2 ,K
,K
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U887*
BPos OM Cam
2887
Function parameter for stop cam operating mode
0 = Edge change
1 = Static
Note:
In the static stop cam operating mode an overtravel of the
cams is not supported which is why the cams have to be
executed up to the end stop!
In function diagram 789a (basic positioner)
Init: 0
Min: 0
Max: 1
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
+ Free blocks
- Upread/free access
Changeable in:
- Ready to switch on
U888*
S.DirPosEnSync
2888
Determines the direction of the position difference of the
master value during synchronization.
Sign of position difference of master value is processed
(U888.01 input value = 0) AND (U888.02 input value = 0)
(U888.01 input value = 1) AND (U888.02 input value = 1)
2.) Positive position differences of master value expected
(U888.01 input value = 1) AND (U888.02 input value = 0)
3.) Negative position differences of master value expected
(U888.01 input value = 0) AND (U888.02 input value = 1)
index1: 0
Unit: -
Indices: 2
Type: L2 ,B
Menus:
- Parameter menu
- Upread/free access
Changeable in:
- Ready to switch on
U890*
Tab Y401-Y450
2890
With this parameter, Y interpolation points 401 to 450 are
entered in the table. The interpolation values are
evaluated only for U615 = 10 to 14. (The X nterpolation
points are then assumed to be equidistant.)
Only for special applications after consultation with the
Applications Center.
Function diagram [839.4]
index1: 0
Min: -
2147483648
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U891*
Tab Y451-Y500
2891
With this parameter, Y interpolation points 451 to 500 are
entered in the table. The interpolation values are
evaluated only for U615 = 10 to 14.
Only for special applications after consultation with the
Applications Center.
Function diagram [839.4]
index1: 0
Min: -
2147483648
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U892*
Tab Y501-Y550
2892
With this parameter, Y interpolation points 501 to 550 are
entered in the table. The interpolation values are
evaluated only for U615 = 10 to 14.
Only for special applications after consultation with the
Applications Center.
Function diagram [839.4]
index1: 0
Min: -
2147483648
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
247
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
