Connector number Connector name Description Double wordDSP
KK0418 FIXSETP KK U018 FB: 8th fixed setpoint 32-bit
in function diagramm: 705.3
yes
no
KK0420 ... KK0422 K-> KK CONV 3 outputs of the K -> KK converter
in function diagram: 710.7
yes
no
K0423 ... K0428 KK-> K CONV 6 outputs of the KK -> K converter.
in function diagram: 710.7
no
no
K0431 B ® K CONV U076 Output of the 1st binector ->
connector.
in function diagram: 720.4
no
no
K0432 B ® K CONV U078 Output of the 2nd binector ->
connector.
in function diagram 720.4
no
no
K0433 B ® K CONV U080 Output of the 3rd binector ->
connector
in function diagram: 720.8
no
no
K0434 ... K0441 AdrCon Service connectors, only for Siemens
service personnel
no
no
K0442 ADD K 0.83 Output of the 1st 16-bit adder.
in function diagram: 725.2
no
no
K0443 ADD K 1.01 Output of the 2nd 16-bit adder
in function diagram: 725.2
no
no
K0444 ADD K 1.42 Output of the 3rd 16-bit adder
in function diagram: 725.3
no
no
K0445 ADD K 2.20 Output of the 4th 16-bit adder.
in function diagram: 725.3
no
no
K0446 ADD 4K 1.57 Output of the 16t-bit adder with 4
inputs.
in function diagram: 725.5
no
no
K0447 SUB K 1.02 Output of the 1st 16-bit subtracter.
in function diagram: 725.2
no
no
K0448 SUB K 1.58 Output of the 2nd 16-bit subtracter
in function diagram: 725.2
no
no
K0449 SUB K 2.06 Output of the 3rd 16-bit subtracter
in function diagram: 725.3
no
no
KK0450 ADD KK 1.15 Output of the 1st 32-bit adder.
in function diagram: 725.2
yes
no
KK0451 ADD KK 1.29 Output of the 2nd 32-bit adder
in function diagram: 725.2
yes
no
KK0452 ADD KK 2.05 Output of the 3rd 32-bit adder
in function diagram: 725.3
yes
no
KK0453 ADD KK 2.21 Output of the 4th 32-bit adder
in function diagram: 725.3
yes
no
KK0454 SUB KK 1.16 Output of the 1st 32-bit subtracter.
in function diagram: 725.2
yes
no
KK0455 SUB KK 2.35 Output of the 2nd 32-bit subtracter
in function diagram: 725.2
yes
no
K0456 MOD ADD K 1.72 Output of the 16-bit adder modulo.
in function diagram: 725.8
no
no
KK0457 MOD ADD KK 1.91 Output of the 32-bit adder modulo
in function diagram: 725.8
yes
no
K0458 VZ INV K 0.84 Output of the 1st 16-bit inverter.
in function diagram: 725.5
no
no
K0459 VZ INV K 1.17 Output of the 2nd 16-bit inverter
in function diagram: 725.5
no
no
K0460 VZ INV K 2.36 Output of the 3rd 16-bit inverter
in function diagram: 725.5
no
no
