Siemens simovert masterdrives

Connector number Connector name Description Double wordDSP
KK0461 VZ INV KK 1.03 Output of the 1st 32-bit inverter.
in function diagram: 725.5
yes
no
KK0462 VZ INV KK 2.22 Output of the 2nd 32-bit inverter
in function daigram: 725.5
yes
no
K0463 SVZ INV K 1.30 Output of the 16-bit switchable inverter
in function diagram: 725.8
no
no
K0464 Wait Time 2.57K Number of loop cycles (calc. time
approx. 1μs) of time slot wait block
no
no
KK0465 SVZ INV KK 1.90 Output of the 32-bit switchable
inverter.
in function diagram: 725.8
yes
no
K0467 MUL K 1.04 Output of the 1st 16-bit multiplier
in function diagram: 730.2
no
no
K0468 MUL K 1.59 Output of the 2nd 16-bit multiplier
in function diagram: 730.2
no
no
K0469 MUL K 2.37 Output of the 3rd 16-bit multiplier
in function diagram: 730.2
no
no
KK0470 MUL KK 1.31 Output of the 32-bit multiplier
in function diagram: 730.2
yes
no
K0471 DIV K 1.05 Output of the 1st 16-bit divider
in function diagram: 730.4
no
no
K0472 DIV K 2.23 Output of the 2nd 16-bit divider
in function diagram: 730.4
no
no
KK0473 DIV KK 1.43 Output of the 1st 32-bit divider
in function diagram: 730.4
yes
no
KK0474 ... KK0478 ConnToPar Value Return value for connector-to-
parameter converter
in function diagram: 798.8
yes
no
K0479 ConnToPar ParNo First parameter number for connector-
to-parameter conversion.
The connector supplies internally all
possible parameter numbers if the
respective index is softwired and
externally only the parameter number
of the first index is shown.
In function diagram: 798.3
no
no
K0480 ConnToPar Index First index number for connector-to-
parameter conversion.
The connector supplies internally all
possible index numbers if the
respective index is softwired and
externally only the index number of
the first index is shown.
In function diagram 798.3
no
no
K0481 MULDIV K 1.06 Output of the 1st 16-bit
multiplier/divider
in function diagram: 730.8
no
no
KK0482 MULDIV KK 1.06 Output of the 1st multiplier/divider (32-
bit intermediate result)
in function diagram: 730.8
yes
no
K0483 MULDIV K 1.32 Output of the 2nd 16-bit
multiplier/divider
in function diagram: 730.8
no
no
KK0484 MULDIV KK 1.32 Output of the 2nd multiplier/divider (32-
bit intermediate result)
in function diagram: 730.8
yes
no
K0485 MULDIV K 1.73 Output of the 3rd 16-bit
multiplier/divider
in function diagram: 730.8
no
no
