Connector number Connector name Description Double wordDSP
KK0486 MULDIV KK 1.73 Output of the 3rd multiplier/divider (32-
bit intermediate result)
in function diagram: 730.8
yes
no
K0490 B->K CONV U057 Output of 4th binector -> connector
converter
Function diagram: 720.8
no
no
K0491 ABSVGEN K 0.75 Output of the 1st 16-bit absolute-value
generator
in function daigram: 735.3
no
no
K0492 ABSVGEN K 2,47 Output of the 2nd 16-bit absolute-
value generator
in function diagram: 735.3
no
no
K0493 ABSVGEN K 2.67 Output of the 3rd 16-bit absolute-value
generator
in function diagram: 735.3
no
no
KK0494 ABSVGEN KK 2.07 Output of the 1st 32-bit absolute-value
generator
in function diagram: 735.3
yes
no
K0495 ... K0496 SR Status Shift register status
K0495: Shift register 1 [FD787a]
K0496: Shift register 2 [FD787b]
no
no
K0497 ... K0498 SR MemDpthAct Current memory depth of shift register
K0497: Shift register 1 [FD787a]
K0498: Shift register 2 [FD787b]
no
no
KK0499 ... KK0500 SR OutputKK Data output double-word connector of
shift register
KK0499: Shift register 1 [FD787a]
KK0500: Shift register 2 [FD787b]
yes
no
K0501 ... K0503 LIMITR K 1.74 1st 16-bit limiter
in function diagram: 735.7
no
no
K0504 ... K0506 LIMITR K 2.38 2nd 16-bit limiter
in function diagram: 735.7
no
no
KK0507 ... KK0509 LIMITR KK 2.48 1st 32-bit limiter
in function diagram: 735.7
yes
no
K0511 ... K0512 LMTMON K 1.18 1st limit-value monitor, 16-bit: fixed
setpoint and output, smooothing
element
in function diagram: 740.2
no
no
K0513 ... K0514 LMTMON K 2.49 2nd limit-value monitor, 16-bit: fixed
setpoint and output, smoothing
element
in function diagram: 740.2
no
no
KK0515 ... KK0516 LMTMON KK 2.68 3rd limit-value monitor, 32-bit: fixed
setpoint and output, smoothing
element
in function diagram: 740.6
yes
no
KK0517 LMTMON KK 1.75 4th limit-value monitor, 32-bit: fixed
setpoint
in function diagram: 740.6
yes
no
K0521 SWITCH K 0.85 1st 16-bit analog switch
in function diagram: 750.2
no
no
K0522 SWITCH K 1.19 2nd 16-bit analog switch
in function diagram: 750.2
no
no
K0523 SWITCH K 1.21 3rd 16-bit analog switch
in function diagram: 750.2
no
no
K0524 SWITCH K 1.60 4th 16-bit analog switch
in function diagram: 750.4
no
no
13
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
